STRAIGHT
SHANK
DRILLS
UDL Jobber Drills - Long Chip
BRIGHT
FINISH
DIN
338
HSS
Co5
TYPE
FS
Continued on next page...
164
Properties
Code
SPLIT POINT
1.5 mm and
above
STANDARD
POINT
sizes below
1.5 mm
