Somta - page 17

PRODUCT SPEC. RANGE CODE
TYPE PAGE
XIII S O M T A P 1 2 C A T A L O G U E
Note: Red denotes Somta Premium Products
348
349
99
100
2 Flute End Mills (Slot Drills)
Regular Length - Threaded Shank
HSS-Co8e - TiAIN Coated and Uncoated
Milling keyways and slots to size in one cut. Designed for plunging
operations. High tensile steels and other difficult materials.
DIN 327
BS 122
1.5-50
1/16-2”
2-50 350 101
2 Flute End Mills (Slot Drills)
Long Series - Threaded Shank
HSS-Co8e - TiAIN Coated and Uncoated
Milling keyways and slots to size in one cut. Designed for plunging
operations. High tensile steels and other difficult materials.
2 Flute End Mills (Slot Drills)
Regular Length - Threaded Shank - HSS
Milling keyways and slots to size in one cut. Designed for plunging operations.
321
323
326
BS 122
2-20
2 Flute End Mills (Slot Drills)
Long Series - Threaded Shank - HSS
Milling keyways and slots to size in one cut. Designed for plunging operations.
1.5-50
1/4-3/4
DIN 327
BS 122
BS 122
97
98
98
310 102
2 Flute End Mills (Slot Drills)
Regular Length - Plain Shank
HSS-Co8e - TiAIN Coated and Uncoated
Milling keyways and slots to size in one cut. Designed for plunging
operations. High tensile steels and other difficult materials.
2-25 DIN 327
305 102
2 Flute End Mills (Slot Drills)
Regular Length - Flatted Shank
HSS-Co8e - TiAIN Coated and Uncoated
Milling keyways and slots to size in one cut. Designed for plunging
operations. High tensile steels and other difficult materials.
DIN 327 2-25
INDEX
SHANK CUTTERS... from previous page
3 Flute End Mills
Regular Length - Threaded Shank
HSS-Co8e - TiAIN Coated and Uncoated
Multi-purpose tool used for slotting and profiling. High tensile steels and
other difficult materials.
342 104 BS 122 3-25
312
2 Flute Ball Nose End Mills
Regular Length - Plain Shank
HSS-Co8e - TiAIN Coated and Uncoated
Milling keyways and slots to size in one cut. Designed for plunging
operations. Produces a radius at the bottom of the cut.
DIN 327 104 2-25
337 103
2 Flute Ball Nose End Mills
Regular Length - Flatted Shank
HSS-Co8e - TiAIN Coated and Uncoated
Milling keyways and slots to size in one cut. Designed for plunging
operations. Produces a radius at the bottom of the cut.
DIN 327 2-25
2 Flute Ball Nose End Mills
Regular Length - Threaded Shank
HSS-Co8e - TiAIN Coated and Uncoated
Milling keyways and slots to size in one cut. Designed for plunging
operations. Produces a radius at the bottom of the cut.
103 340 2-25 DIN 327
Continued on next page...
