PRODUCT SPEC. RANGE CODE
TYPE PAGE
V S O M T A P 1 2 C A T A L O G U E
Note: Red denotes Somta Premium Products
Straight Shank Long Series
Drills - Blue Finish - HSS
For general purpose long reach drilling.
1-16
1/16-5/8
116
117
27-28
Straight Shank Extra Length Drills - Blue Finish - HSS
For extra deep hole drilling.
1.5-13
1/8-1/2
DIN 340
BASED
ON
ISO 3292
121-126
132-136
29
164
1-13
3/64-1/2
No.60-1
LTR.A-U
UDL Jobber Drills - Long Chip
Split Point - Bright Finish - HSS-Co5
Ideal for use on CNC machines where
high productivity and accurate holes are required.
31-32 DIN 338
163 33-35
UDL Stub Drills - Long Chip - Split Point
Bright Finish - HSS-Co5
Ideal for use on CNC machines where
high productivity and accurate holes are required.
DIN 1897
1-13
3/64-1/2
No.60-1
LTR.A-Z
Reduced Shank (Electricians) Drills
Blue Finish - HSS
For general purpose drilling.
26
175
176
11-25
1/2-1”
WORKS
STD.
INDEX
STRAIGHT SHANK DRILLS... from previous page
CBA - Green Band NDX Jobber Drills - HSS-Co5
TiN Coated for drilling Carbon Steel
Ideal for use on CNC machines where
high productivity and accurate holes are required.
23 1-13 DIN 338 1G7
CBA - Red Band UDS Jobber Drills - HSS-Co5
TiAlN Coated for drilling Tough Treatable Steel
Ideal for use on CNC machines where
high productivity and accurate holes are required.
1R5 24 DIN 338 1-13
1-13 22
CBA - Blue Band RF Jobber Drills - HSS-Co5
TiAlN Coated for drilling Stainless Steel (VA)
Ideal for use on CNC machines where
high productivity and accurate holes are required.
1BB DIN 338
CBA - White Band UDC Jobber Drills - HSS-Co5
TiAlN Coated for drilling Cast Iron
Ideal for use on CNC machines where
high productivity and accurate holes are required.
1W6 25 DIN 338 4-12
UDL Long Series Drills - Long Chip - UX Point - Bright Finish - HSS-Co5
Ideal for use on CNC machines
where high productivity and
accurate holes are required. High performance deep hole drilling.
36 109 3-10 DIN 340
154 2-10
UDL Jobber Drills - Long Chip
UX Point - Bright Finish - HSS-Co5
Ideal for use on CNC machines where
high productivity and accurate holes are required.
30 DIN 338
Continued on next page...
